£535.00

Beautifully hand-crafted Field Gate/ Farm Gate manufactured from the finest joinery graded, smooth planed, slow grown Redwood Pine. Traditional time served techniques including mortise, tenon and dowel joints to prevent the frame from “pulling” apart and ensuring a long lasting, durable field gate. Handcrafted in the UK to any width or height. Installation available.

  • STEP 1 | - SELECT SIZE

    TO CALCULATE GATE WIDTH:

    Take three horizontal measurements between existing posts or pillars.

    Where-to-Measure-Driveway-Gate

    Reduce lowest measurement by 130mm.

    *Enter Width (mm): 1200mm to 3600mm

    Actual gate width.

    *Enter Height (mm) 914mm to 1524mm

    Taken to the highest point of the gate inc horns (if design includes this).

    Rate

    Professionally finished. Please note. Colour may look slightly different on the gate due to screen settings. We do offer free samples on request. To order your free sample, please contact us.

    Select Finish

    Professionally finished. Please note. Colour may look slightly different on the gate due to screen settings. Knots on the timber, grain and screws will be visible. We do offer free samples on request. To order your free sample, please contact us.

    .

    *ENTER RAL COLOUR CODE

    Please enter RAL colour code.

    Select Posts

    All posts are 8ft (2m 440mm) in length. Sold online in pairs. If you require single posts, please call to order.

    Heavy Duty Adjustable Hinge Set

    Based on the width you have entered, we recommend the following hinges.

    All hinge sets come with a 5 yr guarantee.

    Select Gate Lock

    Double locking, black and chrome. Includes 5 keys.

    Not fitted. Includes fixings and drill bit.

    AUTOMATION KITS

    Supplied to us by BFT, one of the most reliable automation manufacturers out there. All kits come complete with a 3 year manufacturers guarantee.

    *

Add to wishlist

Need advice?

Call our team on 0800 6124 965
Monday to Friday 8am to 5pm
Email: [email protected]

Trustpilot

0% Finance Available.

Up to £6000. Spread the costs. Apply at checkout or call for more details. More info.

MADE IN THE UK

Expertly Crafted by Hand

All of our gates are expertly crafted by hand in the UK using time served construction techniques. Unlike others, we do not pin our gates together. We use a traditional framing method. Mortise and tenon joints, along with dowels, are a traditional woodworking technique that provide strong and durable connections between frame members. Combining these joints in a wooden frame enhances stability and longevity. When it comes to securing the cladding to the frame, we only use stainless steel screws. Standard screws will rust leading to the gate’s structure to fail over time. Hardwood is a lot more of a stable timber compared to softwood but will expand and shrink during different stages throughout the year. This is completely normal. To protect this, we rebate the inner legs of the gate. This allows the cladding to expand and contract without causing any damage to the frame and without it being noticeable when looking at the gate.

Finish is in the detail. Routered detailing to the edges of the gate, creating a more polished and refined appearance. This decorative touch enhances the overall visual appeal of the gate, making it stand out as a well-crafted and finished piece.

We welcome and encourage our customers to come and visit our factory and see gates being produced for themselves.

Mortise-tenon-and-dowel-jointed-frame

FIELD GATES

How to Measure

Measuring for your new gate is actually a very simple process.

number one with circle   If existing posts/ pillars are in place, take three horizontal measurements. Top, middle and bottom as shown below.

How-to-measure-driveway-gate-width-1

Make a note of the SMALLEST width.

** If you are replacing the posts, take a measurement of the whole opening width and reduce size by the width of the posts. For example: Opening width of 3m 460mm minus 2x posts (at 100mm wide each) = 3m 260mm.

number two in green circleNext, decide how the gate will hang and reduce width accordingly. The is by far the most popular option. Gate is hung between pillars/ posts.

Measure-Farm-or-Field-Gates-4 (1)

Reduce 130mm from lowest measurement (taken from “Step 1”).

Mounted to “REAR” of pillars/ posts.

Measure-Farm-or-Field-Gates-2 (1)

No reduction required.

If ordering online and exact measurement not offered. Reduce to closest size. Want it exact? No problem, call our team to order – 0800 6124 965.

Measuring for Automated Gates:

For above ground automation, rear hung on the back of the posts take the smallest measurement and reduce by 50mm (this will give you the actual gate size to order).For above ground automation, hung in the centre of the posts take the smallest measurement and reduce by 150mm (this will give you the actual gate size to order).For below ground automation, rear hung on the back of the posts take the smallest measurement and plus 20mm (this will give you the actual gate size to order).For below ground automation, rear hung in the centre of the posts take the smallest measurement and reduce by 260mm (this will give you the actual gate size to order).
