Wooden Driveway Gates – The Chappelwood

Trustpilot

Original price was: £865.00.Current price is: £714.00.

Also available in Hardwood and Prime European Oak


  • STEP 1 | - SELECT SIZE

    Actual gate width for both sides added together.

    TO CALCULATE GATE WIDTH:

    Take three horizontal measurements between existing posts or pillars.

    Reduce lowest measurement by 40mm (1 1/2").  This allows for 15mm per side for hinge clearance and 10mm for centre.

    *Enter Width (mm): 1800mm to 6000mm

    Actual gate width for both sides added together. For example, enter 3200mm and receive 2x gate leafs at 1600mm.

    *Enter Height (mm) 914mm to 2134mm

    Taken to the highest point of the gate (inc horns if design has them).

    *Select Horn Design

    Change the design on the side and centre gate horns.

    Professionally finished. Please note. Colour may look slightly different on the gate due to screen settings. We do offer free samples on request. To order your free sample, please contact us.

    Select Finish

    Professionally finished. Please note. Colour may look slightly different on the gate due to screen settings. Knots on the timber, grain and screws will be visible. We do offer free samples on request. To order your free sample, please contact us.

    .

    *ENTER RAL COLOUR CODE

    Please enter RAL colour code.

    Select Posts

    All posts are 8ft (2m 440mm) in length. Sold online in pairs. If you require single posts, please call to order.

    Heavy Duty Adjustable Hinge Set

    Based on the width you have entered, we recommend the following hinges.

    All hinge sets come with a 5 yr guarantee.

    Based on the width you have entered, we recommend the following hinges.

    All hinge sets come with a 5 yr guarantee.

    Based on the width you have entered, we recommend the following hinges.

    All hinge sets come with a 5 yr guarantee.

    Select Gate Lock

    Double locking, black and chrome. Includes 5 keys.

    Not fitted. Includes fixings and drill bit.

    Adding Automation Now or in the Future?

    Extra support for the gate is needed if planning on automating your gates. This is due to the force of the automation to the gate. Standard rails (over time) will fail. Add either a solid middle rail if attaching automation arms to middle of the gate (also know as above ground automation), or bottom middle rail if using underground automation.

    Adding Automation Now or in the Future?

    Extra support for the gate is needed if planning on automating your gates. This is due to the force of the automation to the gate. Standard rails (over time) will fail. Add either a solid middle rail if attaching automation arms to middle of the gate (also know as above ground automation), or bottom middle rail if using underground automation.

    Adding Automation Now or in the Future?

    Extra support for the gate is needed if planning on automating your gates. This is due to the force of the automation to the gate. Standard rails (over time) will fail. Add either a solid middle rail if attaching automation arms to middle of the gate (also know as above ground automation), or bottom middle rail if using underground automation.

    Adding Automation Now or in the Future?

    Extra support for the gate is needed if planning on automating your gates. This is due to the force of the automation to the gate. Standard rails (over time) will fail. Add either a solid middle rail if attaching automation arms to middle of the gate (also know as above ground automation), or bottom middle rail if using underground automation.

    Automation Kits

    By BFT, one of the most reliable automation manufacturers out there. All kits come complete with a 2 year manufacturers guarantee.

    Based on the width you have entered, we recommend the following hinges.

    All hinge sets come with a 5 yr guarantee.

    *

Add to wishlist

Need advice?

Call our team on 0800 6124 965
Monday to Friday 8am to 5pm
Email: [email protected]

Trustpilot

0% Finance Available.

Up to £6000. Spread the costs. Apply at checkout or call for more details. More info.

MADE IN THE UK

Expertly Crafted by Hand

All of our gates are expertly crafted by hand in the UK using time served construction techniques. Unlike others, we do not pin our gates together. We use a traditional framing method. Mortise and tenon joints, along with dowels, are a traditional woodworking technique that provide strong and durable connections between frame members. Combining these joints in a wooden frame enhances stability and longevity. When it comes to securing the cladding to the frame, we only use stainless steel screws. Standard screws will rust leading to the gate’s structure to fail over time. Hardwood is a lot more of a stable timber compared to softwood but will expand and shrink during different stages throughout the year. This is completely normal. To protect this, we rebate the inner legs of the gate. This allows the cladding to expand and contract without causing any damage to the frame and without it being noticeable when looking at the gate.

Finish is in the detail. Routered detailing to the edges of the gate, creating a more polished and refined appearance. This decorative touch enhances the overall visual appeal of the gate, making it stand out as a well-crafted and finished piece.

We welcome and encourage our customers to come and visit our factory and see gates being produced for themselves.

Specification

FRAMED3″ x 3″ (70mm x 70mm) – Mortise, tennon & dowel jointed
REAR BRACING3″ x 2″ (70mm x 47mm)
CLADDINGT, G and V, 19mm Deep x 125mm Wide (nominal)
FIXINGSStainless Steel Screws



Mortise-tenon-and-dowel-jointed-frame
Gate icons

DRIVEWAY GATES

How to Measure

Measuring for your new gate is actually a very simple process.

number one with circle   If existing posts/ pillars are in place, take three horizontal measurements. Top, middle and bottom as shown below.

How-to-measure-driveway-gate-width-1

Make a note of the SMALLEST width.

** If you are replacing the posts, take a measurement of the whole opening width and reduce size by the width of the posts. For example: Opening width of 3m 460mm minus 2x posts (at 100mm wide each) = 3m 260mm.

number two in green circleNext, decide how the gate will hang and reduce width accordingly. The is by far the most popular option. Gate hinges are mounted to the rear of post. A gap of 15mm between edge of gap and post (each side) and a centre gap of 10mm for opening/ closing.

figure-1a-driveway-opening-set-up-example-1

Reduce 40mm off your smallest measurement (from “Step 1”).



Centre Hung

Driveway Gate set up example showing hinges on inside of posts

Reduce 150mm off your smallest measurement (from “Step 1”). Hinges are mounted to the centre of the post. You can mount the driveway gate to be flush with front of the posts but there will be a gap between edge of gate and post of 70mm on each side.

DOWNLOAD GUIDE

WOODEN DRIVEWAY GATES

The Beauty of Redwood Pine

Redwood pine is known for its stunning natural beauty. It has a rich, warm color with prominent grain patterns that add elegance and charm to any gate. Its aesthetic appeal often enhances the overall look of the property. It is a durable wood, especially when properly treated and maintained. It has natural resistance to decay, rot, and insect damage, making it ideal for outdoor applications such as gates. With the right finish and care, a redwood pine gate can last for many years.

ENVIRONMENTAL BENEFITS

Redwood pine is a sustainable option. It is harvested from responsibly managed forests, ensuring that new trees are planted to replace those used. Choosing redwood pine for your gate helps support sustainable forestry practices.

Finish is in the detail. Routered detailing to the edges of the gate, creating a more polished and refined appearance. This decorative touch enhances the overall visual appeal of the gate, making it stand out as a well-crafted and finished piece.

We welcome and encourage our customers to come and visit our factory and see gates being produced for themselves.

GATES AND FENCES UK

Optional Extras

Your Gate…Your Colour

Professionally applied. We offer a range of finish options for your gate. Clear oil, standard range of paint colours:

  • White
  • Anthracite Grey
  • Black
  • Rosewood
  • Grey/ Blue
  • Chartwell Green
  • Pebble grey

Have it your way. Match your home, any RAL colour finish is available.

Your gate - your colour 2

Adjustable Gate Hinges

Available in either galvanised or galvanised and black finish. Heavy duty adjustable gate hinge set which includes:

  • 4x Adjustable Hinges
  • 4x Hinge Pins
  • 2x Drop bolts
  • Brenton bolt
  • Opening Latch
  • Fixings (for gate only)

For gates over 10ft wide, we recommend our 36″ adjustable set.

All hinge sets come with a 5 yr guarantee.

black_driveway_gate_hinges_adjustable_Set

Engraving

Custom engraving. Add your house name, number and road name etc.

Only available on flat top gates.

Engraving on gates

Gate Automation

Add some power!

Above ground kit or below ground kit available. All systems are backed with a manufacturer warranty.

If you are thinking of adding automation to your gate in the future, order your gate with the centre rail, automation ready.

Phobos_BT_Automation Kit

RELATED PRODUCTS

LIMITED TIME SALE! 10% Off all Wooden Gates - use code: AUTUMN10
+ +
  • Precision Guaranteed
  • Time and Date to suit you
  • With you in 2 to 4 days
  • Nationwide - England & Wales

more info…

SPECIALIST

MEASUREMENT SERVICE

£89

Or BOOK ONLINE.
Once payment is in, we’ll contact you to discuss

DELIVERY TIMES

Estimated Delivery Time: Week Commencing 24th November.(Plus an additional 1 week if paint/stain is required.)

Need it faster? Call our team on 0800 6124 965 to discuss our EXPRESS SERVICE.

We offer a two man, white glove service on all of our bigger items. For more info, see here.

SIZE GUIDE

Wooden-Driveway-Gate-Outline-showing-measuring

Width: Total width of gate with both leafs together. Example, order 3m 200mm wide, receive 2x 1m 600mm.

Height: Taken from lowest to highest point of the gate including the horns. We recommend a ground clearance from floor to bottom of gate of 50mm (2″) . If ordering a bow top or swan neck the height difference from highest point of gate to side with the lower side is 304mm (12″).
